Tenda D301 Modem ADSL 2+ Router Wi-Fi N300 with USB 2.0
In The Box
Box Contents : Main Unit, User Manual
Interface : Auto MDI/MDIX
Button : Power, Reset/WPS
External : Power Supply 240 v
Wireless : Standards 802.11n/b/g/3
No. of Antenna 1x
Brand : Tenda
Model : D301
Colour : White
Standard IEEE : 802.11
Frequency : 2.4 ghz
WAN Type : RJ11
DHCP : Yes
VPN-Pass Through PPTP, L2TP, IPSec (ESP Head)
No. of LAN Ports 3x
Signal Rate 300 mbps
Certifications : CE, FCC, RoHS
Access Control : WPA-PSK/WPA2-PSK
Product Dimension :
Length 171.61 mm
Height 34.47 mm
Width 111.16 mm
Operating Temperature 40 c
Storage Temperature 70 c
Operating Humidity 90 %
Storage Humidity 90 %
The Tenda TE-D301 Wireless Router is a 300Mbps Wireless Router, with 2 detachable antennas, 4LAN, 1WAN Port, USB Port (Print Server) & with BSNL, MTNL & Airtel setting pre-configured. This product comes with a 3 year warranty. It is more than just a DSL Modem and Wi-Fi Router, it is a device that combines the function of a high speed ADSL2+ Modem, wireless router and a 4-port switch. The D301 router supports the latest ADSL2/2+ standards in order to provide high performance and long reach of network from ISP’s DSLAM. Use it to connect to the internet and it will provide up to 300 Mbps wireless network for sharing and streaming of videos, music, high-volume files and even online gaming with multiple systems connection. With a versatile USB post, you can share files and media from any external USB storage devices with your friends and family easily.
All-Rounder Device :
Combining the functionality of ADSL 2/2+ modem, WiFi router and 4-port switch, The D-301 is truly a one-stop-solution that serves as a wired and wireless modem and router, with a range of added features such as USB sharing, IPTV, easy setup and TR069.
Enhanced Performance :
You can enjoy bandwidth-intensive activities like online gaming and media with less holdups and better performance, as the D301 is an 802.11n compliant device that delivers wireless speeds of up to 300 Mbps. Also share your media, files, internet access and even printer much faster than before.
Powerful Coverage :
With MIMO technology, the D301 uses signal reflection to reduce dead spots and provide better transmission rates, performance, stability and coverage. It features 2x5dBi external antenna to boost signal and ensure wireless connection all around you.
USB Sharing :
You can also attach an external hard drive or a USB printer to your network, using the USB 2.0 port provided on the router, so that you may share files or print effortlessly form anywhere in your home.
This router features a multi-level encryption option to prevent unauthorized access and protect your important data.
Lightning Protection :
This router is designed with up to 6000 V lightning protection and can effectively avoid damage caused to such electronic device caused due to strong lightning surges. It’s ideal and safe to use in areas which are prone to thunderstorms and lightning frequently.
Hardware Features :
Standards : IEEE 802.11n, IEEE 802.11g, IEEE 802.11b; IEEE 802.3, IEEE 802.3u, ANSI T1.413, ITU.G.992.1, ITU.G.992.2, ITU.G.992.3, ITU.G.992.5
Interface : 1* RJ11 port, 1* USB 2.0, 3* 10/100 Mbps auto-negotiation (Auto MDI/MDIX) Lan ports; 1* 10/100 Mbps WAN/LAN Port Interchangeable port (Auto MDI/MDIX)
Antenna : 2 external Omni-directional antennas
Button : 1x Power, 1x Reset/WPS
Power Input : 100-240V-50/60Hz; Output: 9V DC-1A
Temperature : Operating Temperature 0ᶱC - 40ᶱC; Storage Temperature: -40ᶱC - 70ᶱC
Humidity: Operating Humidity : 10% - 90% RH Non-condensing; Storage Humidity: 5% - 90% RH Non-condensing
Dimensions (L x W x H) mm : 171 x 111.16 x 34.47 mm
LEDs : Power, Internet, DSL, WLAN, LAN, SYS, USB, WPS
Transmission Media : Cat.5, Cat.5e, Cat.6, Telephone Line
Wireless Features :
The wireless speed offered is Up to 300Mbps with a frequency of 2.4GHz. The basic features offered are Wireless Radio: On/Off, SSID Broadcast: On/Off; WDS: On/Off, SSID: Configurable, Channel: Auto 1-13, Network Mode: 11b only, 11g only, 11n only, 11bg mixed, 11bgn mixed and Channel bandwidth: Auto, 20 MHz, 40 MHz. It is also secure with Wireless Security which can be On/Off with 64/128-bit WEP or WPA-PSK/WPA2-PSK.
Internet Connection Type: Dynamic IP; Static IP; PPPoE; PPoA; IPoA
DHCP Server: Yes
Virtual Server: Yes
Security: Port/URL/MAC Filter
VPN Pass-through: PPTP, L2TP, IPsec
Bandwidth Control: Yes
Static Routing: Yes
VLAN: 802.1Q VLAN
The package contains a D301, Power Adapter, Quick Install Guide, Ethernet Cable, ADSL Splitter and 2 Telephone Lines.
Factory Default Settings are as follows - Login IP address: 192.168.1.1; Internet Connection Type Bridge/PPPoE/PPPoA.IPoA/Static IP/Dynamic IP; SSId: Tenda_xxxxxx (“xxxxxx” represents the last six characters in device’s MAC address); Channel: 6; DHCP IP Pool: 192.168.1.2 – 192.168.1.254
